NETGEAR GS108EP

NETGEAR GS108EP, Managed, L2/L3, Gigabit Ethernet (10/100/1000)
In Stock
Reference: GS108EP-100EUS
Reasons to Buy
  • 8 x Gigabit Ethernet ports with PoE+
  • Plug-and-play with fundamental network management features
  • QoS and VLAN management
  • Energy Efficient Ethernet for maximum power savings
  • Fanless and silent
  • Desktop or wall-mount


Technical Headlines
  • Managed L2/L3
  • Quality of Service (QoS) support
  • Basic switching RJ-45 Ethernet ports quantity: 8
  • MAC address table: 4000 entries
  • AC/DC


More Capabilities beyond Plug-and-play Connectivity

Today's growing businesses are both placing more demands on and relying more on their network. Companies are putting more applications and demands on their Ethernet Infrastructure. Using VoIP phones and IP cameras require more than simple plug-and-play connectivity. Additionally, Internet-based applications such as Hotmail and Google Calendaring have made keeping the network up a business-critical need. However, companies do not necessarily have more money or advanced training to deal with complex managed switches. NETGEAR's new ProSafe Plus Switches meet this growing need by providing easy to use visibility and limited confi guration capabilities. To provide more insight into the network behavior, ProSafe Plus Switches offer traffic monitoring for users to observe traffic behavior. Additionally, if there are connectivity issues, these switches offer a cable diagnostic test capability that can identify and even locate problems in the cables. To optimize traffic through the switches, ProSafe Plus Switches offer both port and tag-based prioritization to keep latency-sensitive traffic moving ahead of less critical packets. Also, as a means of improving security or managing collision domains, ProSafe Smart Switches offer VLAN technology. ProSafe Plus Switches offering these monitoring and confi guration capabilities at a slight cost premium over un anaged switches, delivering great value to the end user.

Additionally, furthering NETGEAR's support of the environment, ProSafe Plus Switches have power-saving Green Ethernet technology. The GS108E switch comes in a sturdy metal case with a fan-less design for silent operation.

NETGEAR Green

- Up to 60% lower power consumption than the non-Green version;
- Auto power-down and cable-length detection for energy savings;
- Packaging manufactured with at least 80% recycled materials.
NETGEAR
GS108EP-100EUS

Data sheet

Bandwidth
16 Gbit/s
Basic switching RJ-45 Ethernet ports quantity
8
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Certification
CE, EN, FCC, VCCI
Connectivity technology
Wired
Flow control support
Yes
Housing material
Metal
LED indicators
Activity, Link, PoE, Power, Speed, System
MAC address table
4000 entries
Mean time between failures (MTBF)
859126 h
Networking features
Ethernet, Fast Ethernet, Gigabit Ethernet
Networking standards
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3az
Number of VLANs
64
Operating altitude
0 - 3000 m
Operating relative humidity (H-H)
0 - 90%
Operating temperature (T-T)
0 - 40 °C
Packet buffer memory
1.5 MB
Password protection
Yes
Power over Ethernet (PoE)
No
Power requirements
100 - 240 VAC
Power source
AC/DC
Quality of Service (QoS) support
Yes
Source data-sheet
Icecat.biz
Storage relative humidity (H-H)
0 - 95%
Storage temperature (T-T)
-20 - 70 °C
Supported data transfer rates
10/100/1000 Mbps
Switch layer
L2/L3
Switch type
Managed
Weight
522 g
Product colour
Grey
Compliance certificates
BSMI, CE, Federal Communications Commission (FCC), KC, VCCI

Specific References

EAN13
0606449174632

GS108EP-100EUS.pdf

NETGEAR GS108EP Data Sheet

Download (641.43KB)
