TP-Link ES220GMP

Name: TP-Link ES220GMP
Brand: TP-Link
SKU: ES220GMP

TP-Link Omada ES220GMP, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting

In Stock

Reasons to Buy

16× Gigabit 802.3at/af-compliant PoE+ RJ45 ports
2× Gigabit RJ45 port, 2× Gigabit SFP port
250W Power Budget, with up to 30W for each PoE port*
Easy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional features
Centralized Cloud Management via the web or the Omada app†
Up to 250m PoE**, QoS△, PoE Auto Recovery‡, and Port Isolation for reliable surveillance networking
Automatic Loop Prevention, VLAN, and IGMP Snooping
Durable metal casing and rack-mountable design

Technical Headlines

Managed L2 Web-based management
Quality of Service (QoS) support
Basic switching RJ-45 Ethernet ports quantity: 18
MAC address table: 8000 entries Switching capacity: 40 Gbit/s
Rack mounting
AC Power supply included Power over Ethernet (PoE)

Omada Cloud Essentials - A Free and Easy Cloud-Based Network Mnagement

Omada Cloud Essentials is a free, easy-to-use cloud-based management option for the Omada networking system, covering access points, switches, and gateways. It enables simple, centralized network management and monitoring with essential features, making it ideal for surveillance networks and small businesses that don't require the complexity of larger operations.

Brand TP-Link

Data sheet

10G support: No
AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Auto MDI/MDI-X: Yes
Basic switching RJ-45 Ethernet ports quantity: 18
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Cables included: AC
Depth: 180 mm
Firmware upgradeable: Yes
Flash memory: 64 MB
Flow control support: Yes
Gigabit Ethernet (copper) ports quantity: 18
Heat dissipation: 984.88 BTU/h
Height: 44 mm
LED indicators: Yes
MAC address table: 8000 entries
Mean time between failures (MTBF): 310550.7 h
Networking standards: IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Noise level: 41.5 dB
Number of VLANs: 32
Operating relative humidity (H-H): 10 - 90%
Operating temperature (T-T): -5 - 50 °C
Packet buffer memory: 4 MB
Power over Ethernet (PoE): Yes
Power source: AC
Quality of Service (QoS) support: Yes
Rack mounting: Yes
Source data-sheet: Icecat.biz
Stackable: No
Storage relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -40 - 70 °C
Store-and-forward: Yes
Switch layer: L2
Switch type: Managed
Switching capacity: 40 Gbit/s
User guide: Yes
Web-based management: Yes
Width: 440 mm
Product colour: Black
Cloud-managed: Yes
Power over Ethernet (PoE) type supported: PoE+
Compliance certificates: CE, Federal Communications Commission (FCC), RoHS
Unified static configuration: Yes
