D-Link 28-Port 2.5G Multi-Gigabit PoE++ Smart Managed Switch with 4 x 10G SFP+ Ports

Name: D-Link 28-Port 2.5G Multi-Gigabit PoE++ Smart Managed Switch with 4 x 10G SFP+ Ports
Brand: D-Link
SKU: DMS-1250-28P/B

D-Link 28-Port 2.5G Multi-Gigabit PoE++ Smart Managed Switch with 4 x 10G SFP+ Ports, Managed, L2, 2.5G Ethernet (100/1000/2500), Power over Ethernet (PoE), Rack mounting

In Stock

Reasons to Buy

24 Ports 2.5GE PoE for downlink
4 Ports 10G SFP+ for uplink
PoE IEEE802.3af/at/bt options, power budget 475W
6kV surge protection on all 2.5G ethernet ports
Support LACP 802.3ad Link Aggregation
Support Static Routing & Loopback Detection
Support Spanning Tree Protocol(STP/RSTP/MSTP)
AAA support for RADIUS/TACACS+
Support D-Link Safeguard Engine
Manage through the Nuclias Network Controller

Technical Headlines

Managed L2 Web-based management
Quality of Service (QoS) support Configuring Location Settings (CLI)
Basic switching RJ-45 Ethernet ports quantity: 24
MAC address table: 16000 entries Switching capacity: 200 Gbit/s
Access Control List (ACL)
Rack mounting Stackable
AC Power supply included Power over Ethernet (PoE)

The DMS-1250 Series is D-Link’s newest family of Multi-Gigabit Ethernet smart switches. It provides multi-Gigabit connectivity, Power over Ethernet (PoE) capability, multiple management interfaces and advanced layer 2 features. The DMS-1250 Series provides a high-performace solution to expand your network and adapts to your business needs.

Highlights

Multi-Gigabit Ethernet Connection Delivers fast 2.5 Gbps performance using existing cabling, suitable for Wi-Fi 6 network deployments

10G Uplink Connections
Two 10-Gigabit Ethernet or SFP+ uplink ports allow for additional connections to a storage device or uplink network

Power over Ethernet
PoE+ (30W) or PoE++ (90W) options to simultaneously power multiple types of PoE devices with various power draw requirements

Brand D-Link

Reference DMS-1250-28P/B

Data sheet

AC input frequency: 50/60 Hz
AC input voltage: 100 - 240 V
Auto MDI/MDI-X: Yes
Basic switching RJ-45 Ethernet ports quantity: 24
Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500)
Depth: 250 mm
Flash memory: 32 MB
Flow control support: Yes
Height: 44 mm
Internal memory: 512 MB
LED indicators: Yes
MAC address filtering: Yes
MAC address table: 16000 entries
Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3z
Number of VLANs: 4096
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -5 - 50 °C
Packet buffer memory: 16 MB
Password protection: Yes
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) ports quantity: 24
Power source: AC
Quality of Service (QoS) support: Yes
Rack mounting: Yes
Source data-sheet: Icecat.biz
Spanning tree protocol: Yes
Stackable: Yes
Storage relative humidity (H-H): 0 - 95%
Storage temperature (T-T): -20 - 70 °C
Store-and-forward: Yes
Switch layer: L2
Switch type: Managed
Switching capacity: 200 Gbit/s
Web-based management: Yes
Weight: 4.17 kg
Width: 440 mm
Product colour: Black
