-Link 18-Port 2.5G Multi-Gigabit PoE++ Smart Managed Switch with 2 x 10G SFP+ Ports
  • -Link 18-Port 2.5G Multi-Gigabit PoE++ Smart Managed Switch with 2 x 10G SFP+ Ports
  • -Link 18-Port 2.5G Multi-Gigabit PoE++ Smart Managed Switch with 2 x 10G SFP+ Ports
  • -Link 18-Port 2.5G Multi-Gigabit PoE++ Smart Managed Switch with 2 x 10G SFP+ Ports
  • -Link 18-Port 2.5G Multi-Gigabit PoE++ Smart Managed Switch with 2 x 10G SFP+ Ports

D-Link 18-Port 2.5G Multi-Gigabit PoE++ Smart Managed Switch with 2 x 10G SFP+ Ports

D-Link 18-Port 2.5G Multi-Gigabit PoE++ Smart Managed Switch with 2 x 10G SFP+ Ports, Managed, L2, 2.5G Ethernet (100/1000/2500), Power over Ethernet (PoE), Rack mounting
In Stock
Reference: DMS-1250-18P/B
Reasons to Buy
  • 16 Ports 2.5GE PoE for downlink
  • 2 Ports 10G SFP+ for uplink
  • PoE IEEE802.3af/at/bt options, power budget 370W
  • 6kV surge protection on all 2.5G ethernet ports
  • Support LACP 802.3ad Link Aggregation
  • Support Static Routing & Loopback Detection
  • Support Spanning Tree Protocol(STP/RSTP/MSTP)
  • AAA support for RADIUS/TACACS+
  • Support D-Link Safeguard Engine
  • Manage through the Nuclias Network Controller


Technical Headlines
  • Managed L2 Web-based management
  • Quality of Service (QoS) support Configuring Location Settings (CLI)
  • Basic switching RJ-45 Ethernet ports quantity: 16
  • MAC address table: 16000 entries Switching capacity: 120 Gbit/s
  • Access Control List (ACL)
  • Rack mounting Stackable
  • AC Power supply included Power over Ethernet (PoE)


The DMS-1250 Series is D-Link’s newest family of Multi-Gigabit Ethernet smart switches. It provides multi-Gigabit connectivity, Power over Ethernet (PoE) capability, multiple management interfaces and advanced layer 2 features. The DMS-1250 Series provides a high-performace solution to expand your network and adapts to your business needs.

Highlights

Multi-Gigabit Ethernet Connection Delivers fast 2.5 Gbps performance using existing cabling, suitable for Wi-Fi 6 network deployments

10G Uplink Connections
Two 10-Gigabit Ethernet or SFP+ uplink ports allow for additional connections to a storage device or uplink network

Power over Ethernet
PoE+ (30W) or PoE++ (90W) options to simultaneously power multiple types of PoE devices with various power draw requirements
D-Link
DMS-1250-18P/B

Data sheet

AC input frequency
50/60 Hz
AC input voltage
100 - 240 V
Auto MDI/MDI-X
Yes
Basic switching RJ-45 Ethernet ports quantity
16
Basic switching RJ-45 Ethernet ports type
2.5G Ethernet (100/1000/2500)
Depth
250 mm
Flash memory
32 MB
Flow control support
Yes
Height
44 mm
Internal memory
512 MB
LED indicators
Yes
MAC address filtering
Yes
MAC address table
16000 entries
Networking standards
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3z
Number of VLANs
4096
Operating relative humidity (H-H)
0 - 95%
Operating temperature (T-T)
-5 - 50 °C
Packet buffer memory
12 MB
Password protection
Yes
Power over Ethernet (PoE)
Yes
Power over Ethernet (PoE) ports quantity
16
Power source
AC
Quality of Service (QoS) support
Yes
Rack mounting
Yes
Source data-sheet
Icecat.biz
Spanning tree protocol
Yes
Stackable
Yes
Storage relative humidity (H-H)
0 - 95%
Storage temperature (T-T)
-20 - 70 °C
Store-and-forward
Yes
Switch layer
L2
Switch type
Managed
Switching capacity
120 Gbit/s
Web-based management
Yes
Weight
3.52 kg
Width
440 mm
Product colour
Black

Specific References

EAN13
0790069477843

DMS-1250-18PB.pdf

D-Link 18-Port 2.5G Multi-Gigabit PoE++ Smart Managed Switch with 2 x 10G SFP+ Ports Data Sheet

Download (484.24KB)
